QAC 1450 Twin Power
Two independent generators operating in a single 20 ft ISO container
Combined 1447 kVA prime power with intelligent load sharing
Automatic load management starts and stops each engine to match demand
Up to 40% lower fuel consumption on variable load applications
Continuous power supply during maintenance by operating on a single generator
Advanced touchscreen control with Power Management System (PMS)
Designed for prime, standby and continuous operation
High-performance Scania diesel engines with electronic engine management
Easy transport using a standard ISO CSC container
Mining operations
Industrial facilities
Critical standby power
Commercial buildings
Data centres
Infrastructure projects
Equipment hire and rental fleets
Frequency: 50 Hz
Prime Power (PRP): 1447 kVA / 1158 kW
Standby Power (ESP): 1590 kVA / 1272 kW
Continuous Power (COP): 1117 kVA / 894 kW
Rated Voltage: 400 V (3 Phase)
Power Factor: 0.8
Fuel Consumption @ 100% Load: 277 L/hr
Fuel Consumption @ COP: 211 L/hr
Fuel Tank Capacity: 1,640 L
Operating Temperature: Up to 43°C (derating above 500 m altitude)
Configuration: Twin integrated generators
Engine: 2 × Scania DC16 078A Diesel
Engine Speed: 1500 rpm
Speed Governor: Electronic
Alternator: 2 × Leroy Somer LSA 49.3 M8
Alternator Protection: IP23
Insulation Class: H
Controller: Qc4004 + Qd1001 TwinPower Control System
Container Type: 20 ft ISO CSC Container
Dimensions (L × W × H): 6.06 × 2.50 × 2.60 m
Dry Weight: 14,900 kg
