PAC H86C
An 8" high-head pump engineered for long-distance water transfer and mine dewatering, delivering up to 680 m³/h with a maximum head of 125 m.
High-head vacuum-assisted centrifugal pump delivering up to 680 m³/h (189 L/sec)
Automatic self-priming up to 7.5 m suction lift
Delivers up to 125 m maximum head for high-pressure pumping applications
High hydraulic efficiency of up to 77%
Closed impeller designed for efficient high-head performance
Oil-free diaphragm vacuum pump for reliable dry priming
Heavy-duty ductile iron construction for abrasive and sandy water
Mechanical shaft seal in an oil bath for reliable continuous operation
Long-distance water transfer
High-pressure bypass pumping
Mine dewatering
Deep excavation dewatering
Construction and civil infrastructure projects
Industrial dewatering
Emergency flood response
Max Flow: 680 m³/h (189 L/sec)
Max Head: 125 m
Max Suction Lift: 7.5 m
Solids Handling: 25 mm
Pump Efficiency: Up to 77%
Suction: 8" Flanged
Discharge: 6" Flanged
Engine: Scania DC09 074A Turbo Diesel
Fuel Tank: 420 L
Dimensions (L × W × H): 3250 × 1940 × 2155 mm
Starting: Electric (24V)
Emissions: EPA Tier 2
Control System: PW500 Digital Controller
Priming System: Oil-free diaphragm vacuum pump
