PAC H108
A heavy-duty 10" high-head pump built for large-scale mine dewatering and flood response, delivering up to 1,470 m³/h with a maximum head of 109 m.
High-head vacuum-assisted centrifugal pump delivering up to 1,470 m³/h (408 L/sec)
Automatic self-priming up to 7.5 m suction lift
Delivers up to 109 m maximum head for demanding high-pressure pumping
Exceptional hydraulic efficiency of up to 82%
Closed impeller designed for maximum efficiency and continuous operation
Handles solids up to 89 mm while maintaining high-head performance
Oil-free diaphragm vacuum pump for reliable dry priming
Heavy-duty ductile iron construction with mechanical shaft seal in an oil bath for maximum durability
Large-scale mine dewatering
Long-distance water transfer
High-pressure bypass pumping
Major civil infrastructure projects
Industrial dewatering
Emergency flood response
Large construction dewatering projects
Max Flow: 1,470 m³/h (408 L/sec)
Max Head: 109 m
Max Suction Lift: 7.5 m
Solids Handling: 89 mm
Pump Efficiency: Up to 82%
Suction: 10" Flanged
Discharge: 8" Flanged
Engine: Scania DC09 074A Turbo Diesel
Fuel Tank: 420 L
Dry Weight: 3,900 kg
Dimensions (L × W × H): 3250 × 1940 × 2155 mm
Starting: Electric (24V)
Emissions: EPA Tier 2
Control System: PW500 Digital Controller
Priming System: Oil-free diaphragm vacuum pump
